Skyline-16, P16mm Outdoor Clear Film Glass Adhesive LED Window Glass Video Display
Key Features:
● Flexible PCB technology;
● High brightness 5,000 nits;
● Ultra slim, 3mm thickness;
● Stick & play, no frame;
● Cut freely for your size.
Applications:
Outdoor transparent LED film for window glass advertising media video wall on building, shops, stadium, airport
- Parameters
Key Features:
● Flexible PCB technology;
● High brightness 5,000 nits;
● Ultra slim, 3mm thickness;
● Stick & play, no frame;
● Cut freely for your size.
Applications:
Outdoor transparent LED film for window glass advertising media video wall on building, shops, stadium, airport
Skyline-16, P16mm Flexible Film LED Media Screen
The easiest way to turn your window glass into a media video wall
Skyline Series Transparent film LED display solutions is made of see-through PC and a special self-adhesive material, making it relatively easy to install and use. This super light & ultra-thin film LED display screen, which has a neat appearance, combines seamlessly with the glass surface when the display is turned off, and blends the artistic and sense of technology perfectly.
The transparent film LED screen is easy to paste on any existing glass surface with self-adhesive film without extra structure and turn window glass into stunning, eye-catching video displays, either for advertising or for digital signage display. It can even work on curved glass making it even more versatile. The size and layout of the film can be cut in parallel with the bezel to meet size requirements. It can be expanded by adding more films in a vertical or horizontal way for a big LED video wall.
With a film panel which is 3mm thickness & 4.5 kg per sq.m, Skyline Series transparent film LED display solutions are very easy to handle and setup. This film LED panel has a pixel pitch of 4mm to 20 mm and custom-made panel size, delivering 85% transparency. what's more, the transparent LED display panels have 5000 NIT brightness, it can be widely used in theater, museum, stadium, airport, shopping mall window glass indoor and outdoor.
85% transparency
The special film material ensures 85% transparency, not block nature light in the building.
6000 nits brightness
Extreme brightness 6000nits max, you can enjoy the nature videos during day time outdoor.
Flexible for infinite design
The flexible film offer any shape design, and horizontal & vertical directions installation
Free trimming size
The pixel pitch & film panel size is free to cut for your window glass size.
Ultra thin & light weight
The film panel is only 3mm thickness, weighs 1.6kgs per panel.
Highest Weather protection
Anti-UV material, 10 year’s yellowing resistance.
Easy & neat installation
Paste on window glass with self-adhesive glue-water, fixed with frame of window glass.
Film LED Screen in motion
| Pixel Pitch | 16 mm |
| LED | SMD 2020 |
| Transparency | 86% |
| Film Size (mm) | 960 * 512mm |
| Thickness | 3 mm |
| Material | PC+AL |
| Brightness (Nits) | 3,500 |
| Weight (㎏/㎡) | 2.4 |
| Installation Type | Pasting & Fixed |
| View angle (H/V°) | >140 |
| Power Input | AC 110-220V |
| Grey level | 14 Bit |
| Refresh rate (Hz) | 3840 |
| Max Power Consumption | 300 W/m² |
| Avg Power Consumption | 120 W/m² |
| Driving Type | Static |
| Maintenance | Rear |
| IP Rating | 44 |
| Application | Indoor |
| Life Time (hrs) | 100,000 |
| Operating temp | -10 to 40℃ |
| Storage temperature | -20 to 60℃ |
